What minimum trace isolation and spindle speed does the PCBMaker series achieve?

The PCBMaker series features dedicated high-speed 40,000 RPM and 60,000 RPM spindles (with push-button quick tool change on 60K models) and achieves 0.1 mm (4 mil) copper trace isolation with 15–25 µm Mitutoyo-tested repeatability on FR4, Rogers RF substrates, and MCPCB boards.

What are the PCBMaker 4030 and 5040 models and prices in India?

PCBMaker 4030 40K starts at ₹5,72,250, PCBMaker 4030 60K is ₹6,77,250, PCBMaker 5040 40K is ₹6,66,750, and PCBMaker 5040 60K is ₹7,71,750 (all prices ex-GST, ex-works Bengaluru). All models run on single-phase 220V / 15A power and carry a Lifetime Composite Frame Warranty.

PCBMaker Series

PCBMaker — High-Speed PCB Manufacturing CNC Machines

Batch PCB manufacturing with 40,000 and 60,000 RPM spindle options — 60K models add push-button tool change. Built for repeat runs and 24/7 duty on the composite superstructure.

40,000 & 60,000 RPM Spindles0.1 mm (4 mil) Trace Isolation15–25 µm RepeatabilityStarting ₹5,72,250 ex-GST

Series favourite

PCBMaker 4030 40K

Starting ₹5,72,250

400 × 300 mm3-Axis

High-speed PCB making CNC machine with 40,000 RPM spindle. Designed for fast and precise PCB prototyping and small-scale PCB manufacturing.

Full specs & FAQ → WhatsApp quote

PCBMaker 4030 60K

Starting ₹6,77,250

400 × 300 mm3-Axis

Ultra high-speed PCB CNC machine with 60,000 RPM spindle. Best for high-precision and high-volume PCB prototyping and production.

Full specs & FAQ → WhatsApp quote

PCBMaker 5040 40K

Starting ₹6,66,750

500 × 400 mm3-Axis

Large format high-speed PCB CNC machine with 500×400mm area and 40,000 RPM spindle. Ideal for bigger PCBs, panelized boards, and professional PCB manufacturing.

Full specs & FAQ → WhatsApp quote

PCBMaker 5040 60K

Starting ₹7,71,750

500 × 400 mm3-Axis

Professional grade high-speed PCB CNC machine with 60,000 RPM spindle and 500×400mm working area. Designed for serious PCB manufacturers.

Full specs & FAQ → WhatsApp quote

Which model fits your work?

Start from your problem, not the catalog: PCB & Electronics →

✆ Ask an engineer

All prices are starting prices, ex-GST & shipping.

High-Frequency RF & SMD Prototyping

PCBMaker 40K & 60K RPM Series: Ultra-Fine Trace Isolation

Engineered for electronics R&D labs, defence primes, and university incubators, the PCBMaker series combines ultra-high-speed 40,000 RPM and 60,000 RPM low-runout spindles with height-mapped surface probing to isolate 0.1 mm (4 mil) copper traces on FR4, Rogers RO4003C/RO4350B, and aluminium-backed MCPCB substrates without chemical etching.

PCBMaker 4030 (40K / 60K)

400×300×100 mm working envelope starting at ₹5,72,250 ex-GST (40K) and ₹6,77,250 ex-GST (60K) for dense QFN, BGA, and RF microwave boards.

PCBMaker 5040 (40K / 60K)

Expanded 500×400×100 mm panel bed at ₹6,66,750 ex-GST (40K) and ₹7,71,750 ex-GST (60K) for multi-board array routing, drilling, and depaneling.

Gerber to Board in 30 Minutes

Seamless Gerber and Excellon drill workflow via FlatCAM, TakshakCAM, and auto-leveling Z-probing with 15–25 µm repeatability.
