CXC3 MEGA 53 – 3Axis CNC Machine
3Axis CNC Machine – Made in India – Composite Superstructure
Build Area – 1520 MM / 900 MM / 200 MM
Call / Whatsapp / Telegram – +91 9019054837
Email – contact@akriti.tech
Description
Desktop / Tabletop CNC Machine
A Manufacturing Powerhouse
The CXC3 Mega 53 3Axis CNC Machine from Akriti Precision Systems is a versatile and powerful tool designed for continuous operation on a wide range of materials, including aluminum, copper, brass, bronze, zinc, nickel, gold, silver, wood, plastics, composites, and acrylic. With a build area of 1520x900x200 mm, it caters to the diverse needs of MSME industries.
This machine features a composite superstructure that ensures stability and precision, making it ideal for intricate designs and detailed work. The Arduino Uno R3 controller offers affordability and ease of use, even for those with minimal programming experience. Its open-source nature allows for extensive customization, making it adaptable to various applications.
The CXC3 Mega 53 3Axis CNC Machine includes essential accessories such as cutting and milling bits, collets, and stock holders, ensuring users have everything needed to start their projects. Known for its minimal maintenance and <50 micron repeat positioning accuracy, it guarantees consistent performance. Additionally, it supports online and remote assistance, providing users with reliable support options.
This 3Axis CNC machine is a powerhouse for MSMEs, enabling efficient and precise manufacturing processes across a broad spectrum of materials.
75% Parts
Manufactured in India
25% Parts
Italy, Germany, Japan, Taiwan & Italy
Minimal
Maintenance
<50 Micron Repeat positioning Accuracy
Open Source
SW & HW
Online & Remote
Support Options
Spindle
Authorized dealer
Technical Specifications
Dimensions (Outer) - Length | 1970 MM / 135 CM / 78 In / 6.5 Ft |
Dimensions (Outer) - Width | 1320 MM / 132 CM / 52 In / 4.3 Ft |
Dimensions (Outer) - Height | 730 MM / 73 CM / 29 In / 2.5 Ft. |
Dimensions (Build / Cutting Area) | 1520 MM / 152 CM / 60 In / 5 Ft. |
Dimensions (Build / Cutting Area) | 900 MM / 90 CM / 36 In / 3 Ft. |
Dimensions (Build / Cutting Area) | 200 MM / 20 CM / 08 In / 0.7 Ft. |
Max Stock Height (Z Axis) | 220 MM / 22 CM / 09 In / 0.72 Ft. |
Electronics Board - Dimensions | 360 (L) x 360 (W) x 190 (H) (MM) |
Chassis | Akriti Composite Superstructure |
Max Travel Speed (X Axis) | 6 Meters / Minute |
Max Travel Speed (Y Axis) | 6 Meters / Minute |
Max Travel Speed (Z Axis) | 6 Meter / Minute |
Spindle - Brand | Teknomotor - Air Cooled |
Spindle - Model | COM41470408 |
Spindle - Bearings | Double Bearing |
Spindle - Power | 2.2 KW / 3 HP |
Spindle - Voltage in Volts | 380 / 220 |
Spindle - MAX FREQ. HZ | 400 Hz |
Spindle - MAX RPM | Max 24,000 RPM |
Spindle - Current in Amps (Star / Delta ) | 5.2 / 9.0 A |
Spindle - Weight | 8.5 KGs / 18.7 LBS |
Spindle - Collet | ER 20 |
Spindle Maximum Run-out | Less than 20 Microns / 0.02 MM |
Spindle - Materials Capability | Soft Metals - Aluminium, Copper, Brass, Bronze, Zinc, Nickel, All Non Ferrous metals and alloys. |
Drive - X Axis | Hiwin Rolled Ball Screw & Nut - 20 MM |
Drive - Y Axis | Hiwin Rolled Ball Screw & Nut - 20 MM |
Drive - Z Axis | Hiwin Rolled Ball Screw & Nut - 20 MM |
Guides - X Axis | Hiwin 25 MM Linear Guide & Block - 2 Lengths |
Guides - Y Axis | Hiwin 25 MM Linear Guide & Block - 2 Lengths |
Guides - Z Axis | Hiwin 25 MM Linear Guide & Block - 2 Lengths |
Ball Screw Nut Type | Square Nut |
Stepper Motor (X & Y Axis) - Model | NEMA 34, Bipolar - Stepper Motor (Made in Japan) |
Stepper Motor (X & Y Axis) - Motor type | Hybrid Stepper Motor |
Stepper Motor (X & Y Axis) - No. of steps/rotation | 200 |
Stepper Motor (X & Y Axis) - Holding Torque | 350 NCm |
Stepper Motor (Z Axis) - Model | NEMA 24, Bipolar - Stepper Motor |
Stepper Motor (Z Axis) - Motor type | Hybrid Stepper Motor |
Stepper Motor (Z Axis) - No. of steps/rotation | 200 |
Stepper Motor (Z Axis) - Holding Torque | 210 NCm |
Repeat Positioning Accuracy | <50 Microns / <0.05 MM |
Single Step Movement by Stepper | 2.5 Microns / 0.0025 MM |
Stepper Motor Drivers - Max Current | 7 AMPS |
Stepper Motor Drivers - Voltage Input | 24 - 48 Volts DC |
Stepper Loop Type | Open Loop |
Spindle Control | VFD - Spindle Control |
Stock / Material Fixturing Support | Aluminium - M5 T-slot Profiles - Pre-installed |
Movement | Simultaneous 3 Axis Motion - Full Interpolation |
Machine Movement Type | Moving Gantry System |
Power Input | Single Phase Input - 220V / 110V |
Current | 16 Amp Plug Point Required |
Power Supply | 36 V 10 Amp - SMPS |
Controller | Arduino - USB |
Ship Configuration | Ships Fully Assembled with selected accessories |
Continuous Operations | Certified for 24/7 Operations |
Warranty | 1 Year Warranty - All Parts Covered |
Extended Warranty | Up to 10 Years Extended Warranty - Optional |
Maintenance Contracts | Annual Maintenance Contracts - Optional |
Certification | CE Certified |
CAM Support | Fully compliant with GCODE / MCODE (GRBL) |
OS Support | Windows XP (64 bit), 7, 8, 10, 11, MacOS X, Linux (any), Raspberry Pi / ARM |
Minimum Control PC Specification | 2GB of RAM and a 1280 x 768 screen size |
Recommended Control PC Specification | 8GB of RAM, Intel 8th Gen Processor / AMD Zen 3 Architecture Processor & a minimum 1280 x 768 screen size |
Included PC Specifications | Not included |
Metric / Imperial Support | Supports Both MM & Inches |
Calibrated By | All of our measurements are made with Mitutoyo calibrated instruments |
What items are provided in the package?
The Controller
Arduino Uno R3
Using an Arduino Uno R3 as a controller for CNC machines offers several benefits. First, it provides an affordable and accessible option for hobbyists and small businesses to build their own CNC machines.
The Arduino Uno R3 is widely available and relatively inexpensive, making it an attractive option for those on a budget. Second, the Arduino Uno R3 is easy to use and program, even for those without extensive programming experience.
Its open-source nature means that there are many resources available online, including tutorials and code libraries, to help users get started. Finally, the Arduino Uno R3 offers flexibility and customization options, allowing users to tailor their CNC machines to their specific needs and preferences.
We offer three additional CNC controller options (Upgrades) that can be configured with our CNC machines to enhance their functionality.
The first option is the Parallel Port Controller, which is made in India and features the LinuxCNC operating system.
This controller & PC is embedded in the electronics box of the CNC and is an optional upgrade for a touchscreen interface at an additional cost.
Alternatively we can provide a non-touchscreen option as well.
The second option is the Ethernet Controller, manufactured in Hungary. This controller does not include a PC and is designed to work with any Windows computer (not included).
It provides seamless connectivity and compatibility with a wide range of Windows systems. You can use their own UCCNC Control software or Mach 3/4.
It can be configured with a Touch / Non-Touch PC & monitor combination
TNC-M24 Pendent 3 & 4 Axes CNC Controller
Experience the precision and versatility of the Made in India 4 Axes CNC Controller – TNC-M24. This controller is designed for optimal performance, featuring G-code programmability and step and direction outputs for stepper drivers.
The X, Y, and Z axes provide smooth linear motion, while the fourth axis adds rotational capability as A, B, or C axis, delivering unparalleled flexibility to your system.
Product Warranty
Regarding warranty offerings, we provide comprehensive coverage to ensure your peace of mind. With our OSL Coverage
One Year
Full Warranty, you can enjoy a worry-free first year of ownership, knowing that any manufacturing defects or issues will be promptly addressed.
Six Years
Extended Warranty (optional), allowing you to extend the coverage up to a total of 6 years 1 or 3 years, tailored to your needs.
Lifetime
Lifetime Warranty for the superstructure. This ensures the longevity of your investment and provides enduring protection and assurance. Read more about why we offer this warranty below..
composite superstructure - lifetime warranty
Our products are made from Carbon Fibre & Fibre Glass, Composite Sandwich Structure – Ranging from 5 MM to 25 MM as needed. It provides the following benefits as compared to standard Steel or Aluminium framed CNC’s
- Metal Fatigue – Doesnt suffer form sagging, hoggingor metal fatigue over time.
- Vibration Dampening Properties – Composites have a high loss co-efficient and the structure is able to reduce / absorb vibrations leading to reduced chatter when milling / cutting materials
- Light & Strong – Composites are less dense than steel and are yet comparable to them in Strength & Stiffness
We prepared and got a 6 MM thick piece of composite tested by Underwriters Laboratory. You can access their reports by clicking on theirl logog below.
Options, Upgrades & Accessories
Laser Options
10W Optical Output Laser
with Air Assist
20W Optical Output Laser
with Air Assist
30W Optical Output Laser
with Air Assist
Convert your CNC into a 2-in-1 Machine. Laser Modules can be attached with a magnetic jig to the spindle. Perform basic engraving and cutting tasks of various materials.
Controllers
ParallelPort Controller
Ethernet Controller with UCCNC
Arduino Controller
Coolant & Clamping Systems
38L Coolant Pump & Coolant
Vacuum Clamping System
High Precision Vices, Clamps etc.
Other CNC Accessories/Options
Vacuum Dust Shoe
Bellows & Other Protective Covers
Touch Probes
Upgrade - Ground Ball Screws
8 Micron Accuracy Over 300 MM
Spindle Collets, Cutting Bits
& Spanners
CNC Waterbath - 3 Axis
3 Sizes - Granite / Composites
Design & Control PC's
Industrial Fanless Control PC with Debian LinuxCNC with
22" 7H Hardness - 10 Point Touchscreen Monitor
Industrial Fanless Control PC with Windows 10 Pro with
22" 7H Hardness - 10 Point Touchscreen Monitor
Warranty Options
1 Year Extended Warranty
- Total 10 Years
3 Year Extended Warranty
- Total 10 Years
Spindle Upgrade
Teknomotor CNC Spindle – MODEL – COM41470329
KW – 2.2
V (Δ/Y) – 220/380
MAX FREQ. HZ – 400
MAX RPM – 24,000
CURRENT (Δ/Y) – 9.0 / 5.2
KG’S – 8.48
COLLET – ER 25
BEARINGS – Double Ceramic Bearings
Akriti Videos
Request a Quote For this Machine
Additional information
| Weight | 300 kg |
|---|---|
| Dimensions | 2000 × 1400 × 700 mm |
